Backhoe Loader Parts & Diagrams

Backhoe loader attachment support can include buckets, hydraulic breakers, compactors, augers, grapples and hydraulic thumbs where the machine and auxiliary circuit are compatible. Couplers, hoses and attachment plumbing must match the carrier, flow requirements and coupler interchange. McCann also supports breaker parts, custom hydraulic hose assemblies and attachment and implement service.

Use the machine make, model and serial number, then provide the component position and any visible tag or casting information. Backhoe configurations can vary by production run, drive arrangement, dipper type, controls, coupler and stabiliser setup. Identification from a catalogue photograph or estimated dimensions can result in an incorrect cylinder, pin, valve or filter.

A rebuild may be suitable when the rod, barrel, gland and mounting areas remain serviceable and the fault is primarily seal-related. Replacement or remanufacturing is more appropriate when the rod is bent, chrome is damaged, the bore is deeply scored, the barrel is cracked or mounting damage is present. Inspection and strip-down should determine the repair route.

Common requirements include cylinder seal kits, complete cylinders, hydraulic hoses, couplers, pumps, relief valves, filters, control-valve components, pins, bushings, cutting edges, bucket teeth, adapters and retainers. High-turn items may be available through counter stock, while complete cylinders, pumps, valves and configuration-specific components may require sourcing or exchange.

McCann is an authorised dealer for CASE Construction Equipment, KOBELCO, Takeuchi and BOMAG, and services all makes including CAT, Deere, Komatsu, Bobcat and Kubota. Availability varies by component and machine. Provide the make, model, serial number and component details so the parts counter can confirm OEM, aftermarket or remanufactured options.

Provide the machine make, model and serial number, the component function or position, the existing part number if legible, and photographs or tag information where available. For hydraulic parts, include hose length and fitting details or bring the failed assembly. For remanufactured components, ask about core requirements, warranty coverage, return terms and availability before ordering.

CASE Construction Equipment is the backhoe loader line McCann carries, within a CASE range that also covers excavators, mini excavators, skid steer loaders, compact track loaders, backhoe loaders, wheel loaders, small articulated loaders, dozers, compact dozer loaders, mini track loaders, tractor loaders, rough-terrain forklifts, motor graders, compaction equipment, and attachments. Parts and service for other makes, including CAT, Deere, Komatsu, Bobcat and Kubota, run through the same counter.
